Product Description

The CS range of surge protective devices has been designed for protection against transient overvoltges in single-phase and three-phase electrical power networks.

  • CPT Code
  • Reference
  • Description
  • Technical Info
  • 77705105
  • CS1-15/120
  • Protector against transient overvoltages, type 2, 120 V, 15 kA and one-pole.
  • DOWNLOAD
  • 77705106
  • CS1-15/120 IR
  • Protector against transient overvoltages, type 2, 120 V, 15 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705110
  • CS1-15/230
  • Protector against transient overvoltages, type 2, 230 V, 15 kA and one-pole.
  • DOWNLOAD
  • 77705111
  • CS1-15/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 15 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705115
  • CS1-15/400
  • Protector against transient overvoltages, type 2, 400 V, 15 kA and one-pole.
  • DOWNLOAD
  • 77705116
  • CS1-15/400 IR
  • Protector against transient overvoltages, type 2, 400 V, 15 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705120
  • CS1-40/120
  • Protector against transient overvoltages, type 2, 120 V, 40 kA and one-pole.
  • DOWNLOAD
  • 77705121
  • CS1-40/120 IR
  • Protector against transient overvoltages, type 2, 120 V, 40 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705125
  • CS1-40/230
  • Protector against transient overvoltages, type 2, 230 V, 40 kA and one-pole.
  • DOWNLOAD
  • 77705126
  • CS1-40/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 40 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705130
  • CS1-40/400
  • Protector against transient overvoltages, type 2, 400 V, 40 kA and one-pole.
  • DOWNLOAD
  • 77705131
  • CS1-40/400 IR
  • Protector against transient overvoltages, type 2, 400 V, 40 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705135
  • CS1-65/120
  • Protector against transient overvoltages, type 2, 120 V, 65 kA and one-pole.
  • DOWNLOAD
  • 77705136
  • CS1-65/120 IR
  • Protector against transient overvoltages, type 2, 120 V, 65 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705140
  • CS1-65/230
  • Protector against transient overvoltages, type 2, 230 V, 65 kA and one-pole.
  • DOWNLOAD
  • 77705141
  • CS1-65/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 65 kA, with IR and one-pole.
  • DOWNLOAD
  • 77705149
  • CS1-15N
  • Protector against transient overvoltages, type 2, 15 kA and one-pole (neutral).
  • DOWNLOAD
  • 77705151
  • CS1-40N
  • Protector against transient overvoltages, type 2, 40 kA and one-pole (neutral).
  • DOWNLOAD
  • 77738810
  • CS1-100/230
  • Protector against transient overvoltages, type 1+2, 230 V, 100 kA and one-pole.
  • DOWNLOAD
  • 77738811
  • CS1-100/230 IR
  • Protector against transient overvoltages, type 1+2, 230 V, 100 kA, with IR and one-pole.
  • DOWNLOAD
  • 77738812
  • CS1-100/320
  • Protector against transient overvoltages, type 1+2, 320 V, 100 kA and one-pole.
  • DOWNLOAD
  • 77738813
  • CS1-100/320 IR
  • Protector against transient overvoltages, type 1+2, 320 V, 100 kA, with IR and one-pole.
  • DOWNLOAD
  • 77738814
  • CS1-100N
  • Protector against transient overvoltages, type 1+2, 100 kA and one-phase (one-pole) for neutral.
  • DOWNLOAD
  • 77738815
  • CS1-100/120
  • Protector against transient overvoltages, type 1+2, 120 V, 100 kA and one-pole.
  • DOWNLOAD
  • 77738816
  • CS1-100/120 IR
  • Protector against transient overvoltages, type 1+2, 120 V, 100 kA, with IR and one-pole.
  • DOWNLOAD

CS2 CS2 TWO POLE PROTECTOR

The CS2 and CS2P Type 2 series of surge protective devices have been designed for protection against transient overvoltages in single-phase electrical power networks. The CS2 series does both provide common and differential mode protection for electrical networks with neutral wire. The CS2P series does provide common mode protection for electrical power networks with or without neutral wire.

  • CPT Code
  • Reference
  • Description
  • Technical Info
  • 77705211
  • CS2-15/230
  • Protector against transient overvoltages, type 2, 230 V, 15 kA and single-phase (two-pole).
  • DOWNLOAD
  • 77705212
  • CS2-15/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 15 kA, with IR and single-phase (two-pole).
  • DOWNLOAD
  • 77705228
  • CS2P-15/230
  • Protector against transient overvoltages, type 2, 230 V, 15 kA and two-phase.
  • DOWNLOAD
  • 77705229
  • CS2P-15/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 15 kA, with IR and two-phase.
  • DOWNLOAD
  • 77705241
  • CS2-40/230
  • Protector against transient overvoltages, type 2, 230 V, 40 kA and single-phase (two-pole).
  • DOWNLOAD
  • 77705242
  • CS2-40/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 40 kA, with IR and single-phase (two-pole).
  • 77705242
  • 77705248
  • CS2P-40/230
  • Protector against transient overvoltages, type 2, 230 V, 40 kA and two-phase.
  • DOWNLOAD
  • 77705249
  • CS2P-40/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 40 kA, with IR and two-phase.
  • DOWNLOAD
  • 77705288
  • CS2P-65/230
  • Protector against transient overvoltages, type 2, 230 V, 65 kA and two-phase.
  • DOWNLOAD
  • 77705289
  • CS2P-65/230 IR
  • Protector against transient overvoltages, type 2, 230 V, 65 kA, with IR and two-phase.
  • DOWNLOAD

CS4 FOUR POLE PROTECTOR

The CS4 and CS4P series of Type 2 surge protective devices have been desgined for protection against transient overvoltages in three-phase power networks. The CS4 series does both provide common and differential mode protection for electrical networks with neutral wire. The CS2P series does provide common mode protection for electrical power networks with or without neutral wire.

  • CPT Code
  • Reference
  • Description
  • Technical Info
  • 77705421
  • CS4-15/400
  • Protector against transient overvoltages, type 2, 400 V, 15 kA and three-phase (four-pole).
  • DOWNLOAD
  • 77705422
  • CS4-15/400 IR
  • Protector against transient overvoltages, type 2, 400 V, 15 kA, with IR and three-phase (four-pole).
  • DOWNLOAD
  • 77705428
  • CS4P-15/400
  • Protector against transient overvoltages, type 2, 400 V, 15 kA, three-phase (four-pole) and common mode.
  • DOWNLOAD
  • 77705429
  • CS4P-15/400 IR
  • Protector against transient overvoltages, type 2, 400 V, 15 kA, with IR, three-phase (four-pole) and common mode.
  • DOWNLOAD
  • 77705451
  • CS4-40/400
  • Protector against transient overvoltages, type 2, 400 V, 40 kA and three-phase (four-pole).
  • DOWNLOAD
  • 77705452
  • CS4-40/400 IR
  • Protector against transient overvoltages, type 2, 400 V, 40 kA, with IR and three-phase (four-pole).
  • DOWNLOAD
  • 77705458
  • CS4P-40/400
  • Protector against transient overvoltages, type 2, 400 V, 40 kA, three-phase (four-pole) and common mode.
  • DOWNLOAD
  • 77705459
  • CS4P-40/400 IR
  • Protector against transient overvoltages, type 2, 400 V, 40 kA, with IR, three-phase (four-pole) and common mode.
  • DOWNLOAD
  • 77705488
  • CS4P-65/400
  • Protector against transient overvoltages, type 2, 400 V, 65 kA, three-phase (four-pole) and common mode.
  • DOWNLOAD
  • 77705489
  • CS4P-65/400 IR
  • Protector against transient overvoltages, type 2, 400 V, 65 kA, with IR, three-phase (four-pole) and common mode.
  • DOWNLOAD
